Industrial Connector S1 - Fibre optic cable, Plug LC with click-lock to Plug LC, 1 Gpbs, M24, IP65/67, 3m, Good Connections®
Product number:
IC01-24F01
EAN:
4014619709236
Length:
3 m
Manufacturer article number:
IC01-24F01
Availability:
10-19 available
Description
Product information "Industrial Connector S1 - Fibre optic cable, Plug LC with click-lock to Plug LC, 1 Gpbs, M24, IP65/67, 3m, Good Connections®"
The high-quality, precision-fit and robust connectors from Good Connections® have been developed for the most demanding industrial applications. By using modern production facilities, standardised processes and high-quality materials, a consistently high processing quality of the products is achieved.
Series 1 - metal version with "click" lock.
The quick and easy-to-use "click" closure, in combination with the solid metal / high-performance plastic housing and the gold-plated contacts, reliably ensures secure and stable connection and transmission performance at all times.
Application areas
Good Connections® Industrial Connectors are highly reliable and stable in even the most demanding application scenarios. Wear-resistant, anti-corrosive, waterproof and dustproof - these properties make these connectors all-rounders for use in automation, electronics, energy, communications, lighting and safety technology.
Technical specification:
- Locking technology: "Click
- Protection class: IP65 / IP67
- For M24 cut-outs
- Fibre optic connection cable
- Robust armoured cable design with steel armouring and rodent protection
- Connection 1: LC plug with click lock and plastic cover
- Connection 2: plug LC
- Transmission rate: 1 Gbps
- Durability: > 500 mating cycles
- Operating temperature: -40 °C to +80 °C
- Housing material: metal with zinc alloy (pearl hard chrome) and high-performance plastic
- Sealing: silica gel / silica gel
Length: 3 m
Plug-in compatible products:
- Good Connections® manufacturer no.: IC01-24F01 / EAN: 4014619709236
- Good Connections® manufacturer no.: IC01-24F02 / EAN: 4014619709243
Variants of the series 1
The waterproof Good Connections® Industrial Connectors Series 1 are available in the following variants for M20/M24 cut-outs:
- Power (2-, 3-, 4-, 5-pin)
- Data (USB and HDMI)
- Signal (RJ45, fibre, 5- to 24-pin)
