Industrial Connector S1 - USB 3.2 Gen. 2 cable, plug C™ with click-lock to plug C™, M16, IP65/67, 0,5m, Good Connections®

To order this product, please log in here.

Product number: IC01-16U3101-005

EAN: 4014619881215

Length: 0.5 m

Width: 0.02 m

Height: 0.03 m

Manufacturer article number: IC01-16U3101-005

Availability: 20-49 available

Product information "Industrial Connector S1 - USB 3.2 Gen. 2 cable, plug C™ with click-lock to plug C™, M16, IP65/67, 0,5m, Good Connections®"

The high-quality, precisely fitting and robust connectors from Good Connections® have been developed for the most demanding industrial applications. The use of modern production facilities, standardized processes and high-quality materials ensures consistently high product quality. Series 1 - version with "click" lock The quick and easy-to-use "click" closure, in combination with the solid high-performance plastic housing and gold-plated contacts, reliably ensures a secure and stable data transfer rate of up to 10 Gbit/s and charging power of up to 60 watts at all times. Areas of application The industrial connectors from Good Connections® are highly reliable and stable even in the most demanding application scenarios. Wear-resistant, anti-corrosive, waterproof and dustproof - these properties make these connectors all-rounders for use in automation, electronics, energy, communication, lighting and safety technology. Technical specification: - Locking technology: "Click" - Protection class: IP65 / IP67 / IP68 - For M16 cut-outs - USB connection cable - USB 3.2 Gen. 2 standard, downward compatible - Connection 1: USB-C™ plug with click lock and e-marker chipset - Connection 2: USB-C™ plug - Transfer rate: Super-Speed+, up to 10 Gbit/s data transfer rate - Charging power: max. 60 watts - Durability: > 500 mating cycles - Operating temperature: -40 °C to +85 °C - Housing material: high-performance plastic - Contact material: Copper alloy (gold-plated) - Sealing: Silica gel / silica gel Length: 0,5 m / 50 cm Plug-in compatible products: - Good Connections® Manufacturer No.: IC01-16U3101-005 / EAN: 4014619881215 - Good Connections® Manufacturer No.: IC01-16U3101-010 / EAN: 4014619881222 - Good Connections® Manufacturer No.: IC01-16U3102-005 / EAN: 4014619881239 - Good Connections® Manufacturer No.: IC01-16U3102-010 / EAN: 4014619881246 Variants of series 1 The waterproof Good Connections® Series 1 industrial connectors are available in the following versions for M16/M20/M24 cut-outs: - Power (2-, 3-, 4-, 5-Pin) - Daten (USB und HDMI) - Signal (RJ45, Fiber, 5- bis 24-Pin)
